CAPTURE / RECONSTRUCT / DEVELOP
A physical part. A digital starting point.
Turn existing geometry into useful design data. Capture a part, reconstruct the features that matter, and develop a model for modification, fit studies or manufacturing.
TECHNAST / MARKHAM, ONTARIO
3D scanning & reverse engineering
A clear scope.
A useful result.
- 01
A scan deliverable scoped to the object, surfaces and accessible geometry.
- 02
Mesh cleanup and CAD reconstruction where required.
- 03
Design revisions for interfaces, missing features and replacement concepts.
FROM BRIEF TO BUILD
How the work moves.
- 01
Define the output
Agree whether you need a mesh, editable CAD or a redesigned part.
- 02
Capture the geometry
Plan access, surface preparation and reference measurements.
- 03
Rebuild what matters
Use the scan as a reference for CAD, then check the agreed critical features.
START WITH WHAT YOU HAVE
Bring the challenge.
We’ll shape the next step.
Photos of the object, its size and surface, the required output, important dimensions and whether the physical part is available.
Start a conversationSend an initial message with your email. Files can follow through the secure upload route.
BEFORE WE BEGIN
A few useful answers.
Is a scan the same as editable CAD?
No. A scan normally produces a mesh. Parametric CAD reconstruction is a separate design step.
Can you reproduce a broken part?
We can assess it. Missing geometry needs references or design decisions, and the replacement must be reviewed for its intended use.
